Merrow MB-4DFO 2.0 Activeseam Machine

BOOK YOUR FREE DEMONSTRATION
Watch the MB-4DFO 2.0 in action for yourself in our showroom or via video call from the comfort of your own home. Click HERE to book your in-store or virtual demonstration today.

The NEW MB-4DFO 2.0 is the only machine to sew Merrow’s ActiveSeam for base layer activewear. It has the versatility to all three unique ActiveSeam stitches and can be configured for two or three thread sewing. ActiveSeam 2 is a NEW flat overlock stitch that provides an alternative to flatlock, interlock and overlock stitching on sewn garments.

The MB-4DFO 2.0 sews all three variations of the ActiveSeam stitch. It was specifically developed to sew on base layer garments and the ActiveSeam family of stitches are flat, comfortable, and stretchable stitches that replace traditional flatlock seams. The stitch width can be varied from 3/32″ to 5/32″ according to material properties and/or application requirements and is custom configured to sew specifically using customers’ unique material and thread. Tension settings, eccentrics, and cutter placement are all adjusted to ensure that the customer receives a unique version of the ActiveSeam that is specific to their garment and application.

It utilizes Merrow’s unique barrel cam architecture and curved needles to sew more precisely and consistently than other sewing machines. As the MB-4DFO sews with two needles, it has the versatility to sew three different stitches and with either two or three threads. The MB-4DFO 2.0 is hand-built in the USA and all parts are integrally designed to ensure both stitch superiority and machine durability.

Technical Specification
Sewing Speed: 5550spm
Stitch Width: 3/32″-5/32″
Stitch range: 10-40 stitches per inch
Needle type: A00DF-A2DF
Number of threads: 2-3

Available mounted on a wheeled unit stand with electronic energy saving motor.

Click here for spare parts and accessories.
