Supplied fully assembled on high quality Brinaco RU/C stand with castors,­­ high quality UK manuf­­­ac­­­tured table top & energy saving motor with synchro­niser.

Single needle, Large horizontal axis hook, Compound feed and walking foot, Reverse stitch, Lockstitch machine

Applications:

• For sewing medium to heavy weight materials such as fabrics, leather, vinyl, synthetics and laminated and coated products.
• Suitable for sewing such products as automobile upholstery, covers, sails, tents, camping trailer covers, awnings, bags, luggage, handbags, etc.

Features

Perfect prevention of presser foot's play
A guide was installed to protect play at presser bar bracket. Effective to the works where side force is generated such as piping edge sewing.

Beautiful forward & reverse stitch
More beautiful stitch is realized by the same stitch length adjustment of forward & reverse feed.

Special hook (2 times) & bobbin case opener ideal for heavy weight materials
In case the thread jams in the hook, SEIKO SPECIAL HOOK & SAFETY CLUTCH SYSTEM protect the hook from being damaged. Also perfect stitch is realized by BOBBlN CASE OPENER.

Specifications

Number of needle - Single needle
Max. sewing speed - 2,000 s.p.m. / 2,400 s.p.m.: 8mm or less
Max. stitch length - 10 mm
Clearance under presser foot - by knee 13 mm / by hand 8.5 mm
Needle bar stroke - 33.2 mm
Needle(standard) - 135x17 (standard #140)
Thread - #8 (standard)
Amount of lift of walking foot - 2.7 - 5.5 mm (standard 3.2 mm)
Thread take up lever - Slide type
Lubrication - Semi-automatic lubrication type
Bed size - 477 x 177 mm
Working space - 258 x 110 mm
Net weight(Head only) - 29Kg
